S—04 / CONSTRUCTION MACHINERY
Tube and hose systems shaped around machine interfaces.
We review routed construction-machinery tube and hose components together with connection geometry, clearance, operating environment, joining and inspection requirements.
MM / S—04 Millimeters Matter® ROUTE • CONNECTION • DUTY - Manufacturing
- Project-based
The route follows the drawing and requirements.
- Testing
- Defined criteria
Method and acceptance limits are agreed per product.
01 / INTERFACES
Routing and connection details drive manufacturability.
Tube diameter, wall thickness, bend sequence, fitting geometry, hose connection, clearance and assembly direction are reviewed as one system.
Hydraulic or coolant lines, tube-to-hose assemblies, guards and handrail geometry may require different forming and verification routes; the drawing and operating data determine which processes apply.
02 / OPERATING DATA
Application data is required before a reliable decision.
MM / S—04 / 02 Millimeters Matter® Demanding geometry needs the right process sequence.Provide fluid, pressure, temperature, environmental exposure, duty cycle, test requirements, drawing, quantities and target timing where relevant.
- Tube and hose routing with clearances
- Fitting and mating-interface details
- Fluid, pressure and temperature data
- Test method and acceptance criteria
T—01 / TECHNICAL REVIEW
Review the tube or hose system as a complete interface.
Share the drawing and application conditions so materials, processes and validation needs can be assessed together.
